This JM-LL01 is a Cat M1/NB-IoT asset tracker with ultra-long standby time. its low-cost internal battery can provide up to 3 years of work time on a single charge. The JM-LL01’s strong magnetic mount allows for effortless installation on almost any metal surface and a light sensor will be triggered and an alert sent upon detachment, helping users feel completely confident that their assets are under constant protection.
FEATURES
GPS & LBS Positioning: A synergy of multiple positioning systems ensures that locations are accurately displayed on the cloud platform.
LTE Cat M1/NB2 & GSM:Communications over IoT-specific LTE networks, with reliable 2G GSM fallback.
10,000mAh Rechargeable Battery: High-capacity battery is ideal for long standby applications, and is easily recharged for re-deployment.
Tamper Alert: Receive a tamper alert when the light sensor detects device removal.
IP65 Dust and Water Resistance: Rugged design ensures continued optimal performance, even in the toughest conditions.
Bluetooth Configuration: Fast and simple device configuration via app for iOS.
Strong Magnetic Base: Fast and easy installation via strong magnetic mount or eyelets.
Multiple Working Modes: Configurable working modes according to your actual demands.Ā
SPECIFICATIONS
| GNSS | Ā |
| Positioning system | GPS+LBS |
| Positioning accuracy | ļ¼2.5m CEP |
| Tracking sensitivity | -165dBm |
| Acquisition sensitivity | -148dBm |
| TTFF (open sky) | Avg. hot start ā¤1sec Avg. cold start ā¤40sec |
| Cellular | Ā |
| Communication network | LTE/EGPRS |
| Frequency | LTE Cat M1/NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28/B66 EGPRS: 850/900/1800/1900 MHz |
| Power | Ā |
| Battery | 10,000mAh/3.7V industrial-grade Li-Polymer battery |
| Working modes | Mode 0: Standby mode Mode 1: Tracking mode Mode 2: Power-saving mode |
| Standby time | Up to 3 years in power-saving mode |
| Interface | Ā |
| LED indication | 1 status indicator (Red), 4 battery indicators (Blue) |
| SIM | Standard-SIM |
| Data storage | 32+32Mb |
| Tamper proof | Light sensor |
| Physical specification | Ā |
| Dimensions | 109.0 x 61.0 x 30.5mm |
| Weight | 297g |
| Operating environment | Ā |
| Operating temperature | ā20āĀ to +70ā |
| Operating humidity | 5%ļ½95%, non-condensing |
| IP rating | IP65 |
| Feature | Ā |
| Certificates | FCC, CE, PTCRB, AT&T, TELEC |
| Sensors | 3-Axis Accelerometer |
| Scenarios | Low battery alert, Tamper alert, Vibrating Alert, Over-speed alert, Cover removal alert, Installation alert, Geo-fence |
* We reserve the right of final interpretation of this page. All information is for reference only and is subject to change without further notice.
